Summary0001021: pens in metapost stop working after clipping is used
DescriptionWith ConTeXt ver: 2020.03.10 14:44 MKIV beta fmt: 2020.7.20 with mplib v2.20.5 the following happens:
After a clipping mask is used, pens stop changing thicknesses.
This didn't happen in earlier versions of ConTeXt, nor does it happen with LuaLaTeX with the same mplib.
Steps To Reproduce\starttext
\startMPcode
picture p;
p := image(draw (0, 0)--(1cm, 1cm) withpen pencircle scaled 1cm;);
clip p to (unitsquare shifted (-1/2, -1/2) scaled 10 cm); %this one
draw p;
draw (0, 0)--(-1cm, 1cm) withpen pencircle scaled 1cm;
\stopMPcode
\stoptext

produces a picture with one thick line and one thin line (bug.png), while

\starttext
\startMPcode
picture p;
p := image(draw (0, 0)--(1cm, 1cm) withpen pencircle scaled 1cm;);
draw p;
draw (0, 0)--(-1cm, 1cm) withpen pencircle scaled 1cm;
\stopMPcode
\stoptext

produces two thick lines as intended (nobug.png)
TagsNo tags attached.

Activities

jemmybutton

2020-07-21 01:16

reporter


Hans Hagen

2020-07-21 17:24

manager   ~0001730

fixed in next version (of context)

best report this to the context list or in the context tracker because usually something like this doesn't relate to luatex (where mplib doesn't change) or lualatex / plain (which uses different code)

Hans Hagen

2020-07-21 17:24

manager   ~0001731

fixed in context, no luatex change needed
